A potentiometer in your guitar is most commonly used as a volume, and/or treble-cut tone control. There are of course many combinations of potentiometer and capacitor values you can use for these functions depending on desired sound or pickup type, but sometimes a certain pickups tonal character just needs a little more brightness, or oomph to get the best from it. Something that might not be achievable through the conventional values, so this article looks at 'no-load' pots and how they can be useful in these scenarios.
If you've ever played a guitar without a tone control at all, you may have noticed that the pickup appears as if it yeilds a bit more power, it's brighter and a bit more 'in your face' than equivalent guitars with a tone control in the circuit. For some music or playing styles, this sounds great right? But what if you still want the versatility and adjustability of a tone control from time to time? Well, you can actually have alllll of the cake and eat it you know!
That's where a no-load modded tone pot can really come in handy. But what it is?
A no-load potentiometer is essentially the same as a regular pot, however, at the end of the resistance track it has a slot cut into it so that when you rotate the pot all the way to '10', the wiper is no longer touching the resistance track, effectively placing it out of the circuit. But begin rotating it and the wiper will meet the track once again and function like a regular tone control. You get the best of both worlds so to speak, that extra attack/brightness achieveable when a guitar doesn't have a tone control in the circuit, but with a minor rotation it's in the circuit, influencing the overall tone and of course provides you with a regular tone pot roll off too. This mod might be particularly useful if for example you have a pickup that is a little on the muddy side. You've tried changing pots or different cap values and can't quite coax the top end out of it, then a no-load modded tone pot for that pickup may help a little more, without losing the adjustability of a tone control when you need it.
You can buy some pots with the no-load modification from the factory, brands such as CTS produce these but they're not always available in broader ranges of pot values or bushing sizes. However, it is a simple modification and can be done to any pot providing the casing can be comfortably removed without damaging the pot casing.
If you don't feel comfortable carrying out the mod yourself, then I offer a wide selection of pot types, with the no-load mod done in-house for you. Whether you need a long bushing 500k, extra short bushing solid shaft 250k, 1MEG split shaft, I've got you covered. Check out the in-house modded No-Load pots HERE
Some players worry that they might accidentally knock the tone pot whilst playing, one solution to this are the useful 'notched' no-load pots commissioned by Fender from CTS. They offer these in 250kOhm values only (currently at least) with an extra short bushing (which are suited to pickguards and control plate thicknesses) and with solid or split shafts. I stock those too, and those are available here - SPLIT SHAFT / SOLID SHAFT
How to carry out the mod -
Just a little neccesary disclaimer, I would recommend practicing this on an old pot first, it can take some experience of handling guitar components to do so confidently. This is intended as guidance only. Please take care of yourself and your guitar when carrying out any guitar wiring work and Home of Tone LTD cannot be held responsible for any damage caused by dangerous or incorrect techniques used.
For this mod, you'll need a small flat head screwdriver, a small file (I highly recommend something like a top nut file for example, my go-to is a 0.032" nut file!), some pliers, and a multi-meter. I am basing this on a CTS pot, I can't guarantee that other brands of pot are constructed the exact same way so please keep in mind that this refers to carrying out the no-load mod on a CTS potentiometer.
Step 1 -
Place the pot on a suitable working surface, and with your small flat head screwdriver, gently prise up the 4 back casing retaining tabs. These 4 tabs secure the back casing onto the threaded bushing portion of the pot. With these gently bent back, you can lift off the threaded bushing, and then lift out the bakelite piece which has the resistance track on it.
Step 2 -
With the resistance track piece removed, place it on your working surface so that the track faces upwards. Then with your small file, (again, I personally use and recommend using a top nut file, I like a 0.032" gauge file for the no-load mod), begin to file a slot at the end of the resistance track. Which is the 'end' depends on whether you're modding a regular right handed audio/logarithmic taper pot, or a reverse (left handed) audio/logarithmic taper pot for example. But in this photo, I am modding a regular right handed audio taper pot, so the 'end' of the track so to speak, is situated on the left hand side of the track.
You don't need to file right the way through the track, just a notch is sufficient as shown in the photo above.
Step 3 -
With the notch cut, carefully blow away the debris caused by filing, check everything over and re-assemble the pot. Placing the bakelite piece back into the casing, the threading bushing, and then bend back the 4 casing securing tabs. With your multi-meter, set to the relevent Ohms setting, test your pot by placing one probe on the central wiper lug, and the other probe on the left hand lug (with the lugs facing you and the pot shaft pointing upwards). With it rotated to '10' so to speak, you should see no reading at all, then begin rotating the shaft and you should see a reading spring to life.
And there we have it! A little run down of why a no-load tone pot can be really useful, info on where to source one, or carry out the mod yourself should you have the right tools to hand. I hope this all helps with your guitar tone journey!
James
