McNelly JellyBucker Humbucker Pickup
Please use the tabs below to read through the information about this product.
Availability
This specific bridge pickup is in stock and ready for dispatch.
About the JellyBucker humbucker
The JellyBucker has an unassuming name and will use that against you if you're not careful! We haven't seen too many 'hot' pickups in the McNelly pickup range over the years, so I think this is a great addition!
Wound to ~16k, it makes for an awesome screaming option in a HSS set, or a high output boost in any HH guitar. It's punchy with a surprising amount of cut. Looking for a good neck humbucker to pair this with? then the Clarity Humbucker neck pairs well as a set.
1 15/16" string spacing
Only available in the bridge position.
Nerdy specs
Type - Passive
Wire type - 2 wire (braided)
DCR bridge - 16kOhm
Magnet direction - Screw coil South to strings, Slug coil north to strings
Recommended wiring - The JellyBucker pickup will suit 500k pots and a 0.022uF tone cap well.
Will it fit my guitar?
The JellyBucker is standard PAF sizing, with short leg mounts.
Cover Options
This in stock pickup has no cover, and has black bobbins for both coils.
What's included?
Inside the box you'll find the pickup you have ordered, along with your mounting screws and height rubbers.
Installation
This model JellyBucker is traditional 'PAF' type humbucker size, and has 'short leg' mounts. They are traditional braided as standard (Gavitt 22awg cloth style wire where outer braiding is ground, central black cloth covered wire is 'hot'). If by chance you aren't comfortable installing these pickups yourself, and are local to the Home of Tone, then I offer professional in-house installation. If you are installing them yourself, then I am of course here for any installation advise too.
